Removal & Installation

Disconnect negative battery cable. Remove instrument panel. See INSTRUMENT PANEL . Disconnect connector. See Fig 1. Remove 4 screws and electronic blend door actuator. See Fig 2. To install, reverse removal procedure.

Fig 1: Identifying Electronic Blend Door Actuator Connector

Courtesy of FORD MOTOR CO.

Fig 2: Removing & Installing Electronic Blend Door Actuator

Courtesy of FORD MOTOR CO.
