| 1 |
... |
not used |
| 2 |
... |
not used |
| 3 |
... |
not used |
| 4 |
1 (DB) |
Horn (13832), control |
| 5 |
... |
not used |
| 6 |
220 (VT/OG) |
Autolamp On/Off signal |
| 7 |
218 (WH/VT) |
Autolamp sensor |
| |
296 (WH/VT) |
Voltage in Run or Accessory (overload protected) |
| 8 |
217 (DB/OG) |
Autolamp time delay signal |
| 9 |
383 (RD/WH) |
Emergency warning flasher, feed |
| 10 |
344 (BK/YE) |
Driver Door module, Lighting control module |
| 11 |
867 (DB) |
Door ajar switch, driver side front (14018) |
| 12 |
688 (GY/LB) |
Rear window defrost relay, control |
| 13 |
... |
not used |
| 14 |
183 (TN/YE) |
Voltage, hot in run only |
| 15 |
1036 (BN/WH) |
Instrument panel dimming module, Instrument illumination |
| 16 |
1035 (OG/RD) |
Instrument panel dimming module, Instrument illumination |
| 17 |
1083 (LB/BK) |
Air bag, tone driver |
| 18 |
1010 (DB/OG) |
Rear window defrost switch (18578), input |
| 19 |
... |
not used |
| 20 |
... |
not used |
| 21 |
... |
not used |
| 22 |
... |
not used |
