Diagnostic Aids
WARNING: This page is about a different variant/trim than selected.
Perform this test when instructed during QUICK TEST or if directed by other test procedures. This test is used to diagnose the following:
- Wiring Harness Circuits: (AIRB, B+, EAIR, EAIR MONITOR & GND)
- Solid State Relay (SSR)
- Electric Secondary Air Injection (AIR) Pump. See Fig 2.
- Secondary Air Injection (AIR) By-Pass Solenoid
- Powertrain Control Module (PCM)
- Secondary Air Injection (AIR) Diverter Valve
- Vacuum Supply & Hoses
- Air Silencer
- Secondary Air Injection (AIR) Check Valve
- Partial Restricted Exhaust
