Injector-Fuel 4 (2.9L) Connector End View (D5217A)

Harness-Family: Injector_LT

Color: BLACK

Gender: FEMALE

Part Number: 1/11712/97

Part Description: Not Available

Connector No: D5217A

Option: 2.9L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Injector-Fuel 4 Connector End View (2.9L)

Courtesy of CHRYSLER

Fig 2: Injector-Fuel 4 Component Location (2.9L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K14

DB/BK

0.75

INJECTOR 4 CONTROL

2.9L

K614

DB/RD

0.75

INJECTOR 4 LOW SIDE CONTROL

2.9L

⁽¹⁾	Pins not listed are not used for this connector
