Lamp-Vanity-Left (Standard) Connector End View (D4591A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 1/08332/07

Part Description: Not Available

Connector No: D4591A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Vanity-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Lamp-Vanity-Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A903

RD/BK

0.5

FUSED B(+)

N/A

Z332

0.5

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
