Motor-Seat Lumbar Pump-Passenger (Except Bolster) Connector End View (D2849A)

Harness-Family: Seat_Passenger

Color: BLACK

Gender: FEMALE

Part Number: 1456985-1

Part Description: Not Available

Connector No: D2849A

Option: EXCEPT BOLSTER

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Motor-Seat Lumbar Pump-Passenger Connector End View (EXCEPT BOLSTER)

Courtesy of CHRYSLER

Fig 2: Motor-Seat Lumbar Pump-Passenger Component Location (EXCEPT BOLSTER)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P171

0.5

LUMBAR UPWARD PASS

EXCEPT POWER BOLSTER

P108

0.5

PASSENGER SEAT LUMBAR IN DRIVER

EXCEPT POWER BOLSTER

Z332

0.5

GROUND

EXCEPT POWER BOLSTER

P173

0.5

LUMBAR DOWNWARD PASS

EXCEPT POWER BOLSTER

P106

0.5

PASSENGER SEAT LUMBAR OUT DRIVER

EXCEPT POWER BOLSTER

⁽¹⁾	Pins not listed are not used for this connector
