Relay-PTC 3 (Standard) Connector End View (D872A)

Harness-Family: HVAC

Color: BLACK

Gender: FEMALE

Part Number: 2-953615-2

Part Description: Not Available

Connector No: D872A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Relay-Ptc 3 Connector End View (Standard)

GCWD1006402

Courtesy of CHRYSLER

Fig 2: Relay-Ptc 3 Component Location (Standard)

GCWD1267217

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K363

PK

0.5

PTC 3 RELAY CONTROL

N/A

2

Z910

BK/VT

1.5

GROUND

N/A

3

A901

DB

8

FUSED B(+)

N/A

5

F288

BN

8

FUSED CABIN HEATER 3 SUPPLY

N/A

⁽¹⁾	Pins not listed are not used for this connector
