S138 (Standard) Connector End View (S138)

Harness-Family: Headlamp_Dash

Color: NA

Gender: FEMALE

Part Number: AGV36375

Part Description: Not Available

Connector No: S138

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: S138 Connector End View (Standard)

GCWD1006420

Courtesy of CHRYSLER

Fig 2: S138 Component Location (Standard)

GCWD1267632

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

L960

VT/GY

0.35

HEADLAMP LEVELING SENSOR FRONT SIGNAL

BASE

2

L960

VT/GY

0.35

HEADLAMP LEVELING SENSOR FRONT SIGNAL

BASE

3

L960

VT/GY

0.35

HEADLAMP LEVELING SENSOR FRONT SIGNAL

BASE

⁽¹⁾	Pins not listed are not used for this connector
