Assembly-Power Distribution Center-Front C1 (Standard) Connector End View (D6630A)

Harness-Family: Headlamp_Dash

Color: NA

Gender: FEMALE

Part Number: 1608530/10

Part Description: Not Available

Connector No: D6630A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Assembly-Power Distribution Center-Front C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Assembly-Power Distribution Center-Front C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

35.0

B(+)

2.0L/2.2L

⁽¹⁾	Pins not listed are not used for this connector
