Seat Belt-Retractor TENSIONER Rear-Left (Standard) Connector End View (D3244A)

Harness-Family: Body

Color: YELLOW

Gender: FEMALE

Part Number: 1/16287/91

Part Description: Not Available

Connector No: D3244A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Seat Belt-Retractor Tensioner Rear-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Seat Belt-Retractor Tensioner Rear-Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R35

0.5

2R SEAT BELT RETRACTOR PRET (+) LT

EXPORT

R37

GY/BK

0.5

2R SEAT BELT RETRACTOR PRET (-) LT

EXPORT

⁽¹⁾	Pins not listed are not used for this connector
