Sensor-Engine Coolant Temperature 2 (2.9L) Connector End View (D1649A)

Harness-Family: Injector_LT

Color: BLACK

Gender: FEMALE

Part Number: 15397337

Part Description: Not Available

Connector No: D1649A

Option: 2.9L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Engine Coolant Temperature 2 Connector End View (2.9L)

Courtesy of CHRYSLER

Fig 2: Sensor-Engine Coolant Temperature 2 Component Location (2.9L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K25

BN/OG

0.5

ECT 2 SIGNAL

2.9L

K917

GY/BK

0.5

SENSOR GROUND

2.9L

⁽¹⁾	Pins not listed are not used for this connector
