Sensor-Exhaust Gas Temperature Turbine (2.2L) Connector End View (D2521A)

Harness-Family: Engine_22L

Color: BLACK

Gender: FEMALE

Part Number: 1/11585/97

Part Description: Not Available

Connector No: D2521A

Option: 2.2L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Exhaust Gas Temperature Turbine Connector End View (2.2L)

Courtesy of CHRYSLER

Fig 2: Sensor-Exhaust Gas Temperature Turbine Component Location (2.2L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K384

GN/WH

0.5

EGT SIGNAL

DIESEL

K385

VT/YE

0.5

SENSOR GROUND

DIESEL

⁽¹⁾	Pins not listed are not used for this connector
