Solenoid-Fuel Pressure (2.2L) Connector End View (D17A)

Harness-Family: Engine_22L

Color: BLACK

Gender: FEMALE

Part Number: 1/06044/97

Part Description: Not Available

Connector No: D17A

Option: 2.2L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Solenoid-Fuel Pressure Connector End View (2.2L)

Courtesy of CHRYSLER

Fig 2: Solenoid-Fuel Pressure Component Location (2.2L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K179

YE/GY

0.75

FUEL RAIL PRESSURE SIGNAL 1

DIESEL

K180

BN/RD

0.75

SENSOR RETURN

DIESEL

⁽¹⁾	Pins not listed are not used for this connector
