Valve-Hp EGR (2.2L) Connector End View (D16A)

Harness-Family: Engine_22L

Color: BROWN

Gender: FEMALE

Part Number: 1/07797/98

Part Description: Not Available

Connector No: D16A

Option: 2.2L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Valve-Hp Egr Connector End View (2.2L)

GCWD1087809

Courtesy of CHRYSLER

Fig 2: Valve-Hp Egr Component Location (2.2L)

GCWD1267264

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K834

GY/RD

0.75

EGR 5 VOLT SUPPLY

DIESEL

2

K684

DB

0.5

EGR CONTROL 2

DIESEL

4

K934

VT/RD

0.5

EGR SENSOR GROUND

DIESEL

5

K683

YE/GN

0.75

EGR SIGNAL

DIESEL

6

K682

DB/WH

0.5

EGR CONTROL 1

DIESEL

⁽¹⁾	Pins not listed are not used for this connector
