Lamp-Map Pocket Rear Left (Standard) Connector End View (D2680A)

Harness-Family: Door_Left_Rear_Jumper

Color: GRAY

Gender: FEMALE

Part Number: 2138557-2

Part Description: Not Available

Connector No: D2680A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Map Pocket Rear Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Lamp-Map Pocket Rear Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

M108

YE/GN

0.5

AMBIENT LIGHTING CONTROL

PREMIUM

Z332

WH/BK

0.5

GROUND

PREMIUM

⁽¹⁾	Pins not listed are not used for this connector
