Module-Anti-Lock Brakes C2 (Standard) Connector End View (D3863B)

Harness-Family: Headlamp_Dash

Color: BLACK

Gender: FEMALE

Part Number: 7287-1990-30

Part Description: Not Available

Connector No: D3863B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Anti-Lock Brakes C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Anti-Lock Brakes C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A901

10.0

FUSED B(+)

N/A

Z105

10.0

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
