Motor-Window-Passenger (Standard) Connector End View (D3063A)

Harness-Family: Door_Front_Pass

Color: BLACK

Gender: FEMALE

Part Number: 1/13019/97

Part Description: Not Available

Connector No: D3063A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Motor-Window-Passenger Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Motor-Window-Passenger Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A901

RD/GN

2.5

FUSED B(+)

N/A

Q336

BN/GN

0.5

PASSENGER WINDOW SWITCH MUX

N/A

Z332

0.5

GROUND

N/A

D403

GN/YE

0.35

LIN BUS 3

N/A

Z332

2.5

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
