Rear Sensors

REMOVAL

1. Disconnect and isolate the negative battery cable.
2. Remove the rear fascia. Refer to FASCIA, REAR, REMOVAL AND INSTALLATION Refer to FASCIA, REAR, LOWER, REMOVAL AND INSTALLATION .

   Courtesy of CHRYSLER GROUP, LLC

3. Release the Park Assist Sensor (PAS) from the PAS retaining clips (1a).
4. Disconnect the wiring harness connector (2a) from the PAS.
5. Remove the PAS.

INSTALLATION

1. Inspect the PAS, PAS retaining clips and the PAS wiring integrity.

   Courtesy of CHRYSLER GROUP, LLC

2. Connect the wiring harness connector (1a) to the PAS (1b).
3. Install the PAS to the PAS sensor housing allowing the PAS retaining clips (2a) to engage.
4. Install the rear fascia. Refer to FASCIA, REAR, REMOVAL AND INSTALLATION Refer to FASCIA, REAR, LOWER, REMOVAL AND INSTALLATION .
5. Connect the negative battery cable.
