Removal And Installation: Removal

NOTE:

2.9L equipped vehicle shown in illustration. 2.0L equipped vehicle typical.

Courtesy of CHRYSLER GROUP, LLC

Undo the screws (1a) and remove the underbody tunnel reinforcement crossmember (1b).

Courtesy of CHRYSLER GROUP, LLC

INSTALLATION

Place the underbody tunnel reinforcement crossmember (1a) in its housing and tighten screws (1b) to the proper specification. Refer to TECHNICAL SPECIFICATIONS .
