Removal - 2.0L

Courtesy of CHRYSLER GROUP, LLC

1. Raise and support the vehicle. Refer to HOISTING, STANDARD PROCEDURE .
2. Undo the screws (1a) fixing the rear underbody guard (1b).
3. Retain the guard (1b).

Courtesy of CHRYSLER GROUP, LLC

INSTALLATION

1. Position the control unit (1a).
2. Tighten the bolts (2a) fixing the guard (1a).
