Removal And Installation: Removal

Courtesy of CHRYSLER GROUP, LLC

1. Raise and support the vehicle. Refer to HOISTING, STANDARD PROCEDURE .
2. Remove the screw (1a) securing the side guard (1b).
3. Remove the nuts (2a).
4. Remove the retaining clip (3a), using the appropriate tool.
5. Lower the car, then release the front arm (4a) from the lift.
6. Remove the side protection (1b).

Courtesy of CHRYSLER GROUP, LLC

INSTALLATION

1. Position the side guard (1a), the front arm (1b) and the arms on the lift.
2. Position the side guard (1a), following the overlapping order with the other guards, as shown in illustration, then engage the retainer clips (2a).
3. Install the nuts (3a) and securely tighten.
4. Install the screw (4a) and securely tighten.
