DNA Driving Mode Selector

REMOVAL

1. Disconnect and isolate the negative battery cable.
2. Remove the shifter bezel. Refer to BEZEL, SHIFTER, REMOVAL AND INSTALLATION .

   Courtesy of CHRYSLER GROUP, LLC

3. Remove the bolts (1a).
4. Remove the Vehicle Dynamic (DNA) selector switch (1b) from the shifter bezel.

INSTALLATION

1. Inspect the integrity of the DNA selector switch.

   Courtesy of CHRYSLER GROUP, LLC

2. Position the selector switch (1a) to the shifter bezel for installation.
3. Using screws (1b), secure the selector switch to the shifter bezel.
4. Install the shifter bezel. Refer to BEZEL, SHIFTER, REMOVAL AND INSTALLATION .
5. Connect the negative battery cable.
