Actuator-RECIRCULATION Door (Standard) Connector End View (D10A)

Harness-Family: HVAC

Color: BLACK

Gender: FEMALE

Part Number: 1-969489-1

Part Description: Not Available

Connector No: D10A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Actuator-Recirculation Door Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Actuator-Recirculation Door Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C333

BK/VT

0.35

ACTUATOR GROUND

N/A

C144

BN/WH

0.35

RECIRC DOOR SIG

N/A

C26

WH/GN

0.35

REFERENCE VOLTAGE SUPPLY

N/A

C68

GY/RD

0.35

RECIRCULATION DOOR DRIVER 1

N/A

C268

BN/BK

0.35

RECIRCULATION DOOR DRIVER 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
