Sensor-Body Acceleration-Left Front (Standard) Connector End View (D2558A)

Harness-Family: Headlamp_Dash

Color: BLUE

Gender: FEMALE

Part Number: 1-1924067-6

Part Description: Not Available

Connector No: D2558A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Body Acceleration-Left Front Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Body Acceleration-Left Front Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

S162

WH/BK

0.35

BODY ACCELERATION SENSOR SIGNAL FT LT

PREMIUM

S161

WH/YE

0.35

BODY ACCELERATION SENSOR RTN FT LT

PREMIUM

⁽¹⁾	Pins not listed are not used for this connector
