Sensor-Brake Pad-Rear Left (Standard) Connector End View (D2919A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 1/24524/87

Part Description: Not Available

Connector No: D2919A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Brake Pad-Rear Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Brake Pad-Rear Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

B180

OG/WH

0.35

BRAKE PAD WEAR SIGNAL

2.0L/2.2L

⁽¹⁾	Pins not listed are not used for this connector
