Sensor-Front Impact-Right (Standard) Connector End View (D1527A)

Harness-Family: Headlamp_Dash

Color: BLUE

Gender: FEMALE

Part Number: 1-1924067-6

Part Description: Not Available

Connector No: D1527A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Front Impact-Right Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Front Impact-Right Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R80

0.35

RIGHT FRONT IMPACT SENSOR SIGNAL

N/A

R82

GY/BK

0.35

RIGHT FRONT IMPACT SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
