Sensor-Oil Temperature-Motor Torque-Right (Standard) Connector End View (D3067A)

Harness-Family: Rear_Differential

Color: BLACK

Gender: FEMALE

Part Number: 1/11585/97

Part Description: Not Available

Connector No: D3067A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Oil Temperature-Motor Torque-Right Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Oil Temperature-Motor Torque-Right Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T446

YE/RD

0.5

RIGHT TORQUE MOTOR OIL TEMPERATURE SENSOR SIGNAL

N/A

T447

BK/VT

0.5

RIGHT TORQUE MOTOR OIL TEMPERATURE SENSOR RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
