Sensor-Particulate Matter (2.2L EU6) Connector End View (D2800A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 1-1456426-5

Part Description: Not Available

Connector No: D2800A

Option: 2.2L EU6

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Particulate Matter Connector End View (2.2L EU6)

Courtesy of CHRYSLER

Fig 2: Sensor-Particulate Matter Component Location (2.2L EU6)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z341

GROUND

EU6

D468

BN/BK

0.35

PRIVATE CAN (-)

EU6

D469

YE/GN

0.35

PRIVATE CAN (+)

EU6

F205

DB/RD

SCR RELAY 3 OUTPUT

EU6

⁽¹⁾	Pins not listed are not used for this connector
