Air Outlet - Left Outer: Installation

NOTE:

Take the proper precautions to protect the instrument panel from cosmetic damage.

GC0194176Courtesy of CHRYSLER GROUP, LLC
  1. Position the air outlet (1b) to the instrument cluster bezel and engage the retaining clips (1a). Be certain the retainers (1a) are fully engaged.
  2. Connect the negative battery cable. If equipped with an Intelligent Battery Sensor (IBS), connect the IBS connector.
