Latch-Door-Left Rear (Standard) Connector End View (D6617A)

Harness-Family: Door_Left_Rear

Color: BLACK

Gender: FEMALE

Part Number: 1/08359/87

Part Description: Not Available

Connector No: D6617A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Latch-Door-Left Rear Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Latch-Door-Left Rear Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P371

VT/RD

0.35

DOOR LOCK SW RTN DRIV

N/A

P372

0.35

DOOR LOCK SW RTN PASS

N/A

G77

WH/BN

0.35

LEFT REAR DOOR AJAR SWITCH SENSE

N/A

P33

WH/BK

DOOR LOCK DRIVER

N/A

OG/GN

DOOR UNLOCK DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
