Module-Heated Seats C2 (Standard) Connector End View (D3846B)

Harness-Family: Seat_Passenger

Color: BLACK

Gender: FEMALE

Part Number: 1376675-1

Part Description: Not Available

Connector No: D3846B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Heated Seats C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Heated Seats C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D157

PK/DB

0.35

CAN IHS (+)

REAR HEATED SEATS

D158

BU/BK

0.35

CAN IHS (-)

REAR HEATED SEATS

P968

YE/DB

0.5

HEATED SEAT SENSOR RETURN

REAR HEATED SEATS

P672

BN/VT

0.5

LEFT REAR HEATED SEAT TEMP SENSE

REAR HEATED SEATS

P673

GY/RD

0.5

RIGHT REAR HEATED SEAT TEMP SENSE

REAR HEATED SEATS

⁽¹⁾	Pins not listed are not used for this connector
