Coil-Ignition 5 (2.9L) Connector End View (D5208A)

Harness-Family: Injector_LT

Color: BLACK

Gender: FEMALE

Part Number: 1/08822/97

Part Description: Not Available

Connector No: D5208A

Option: 2.9L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Coil-Ignition 5 Connector End View (2.9L)

GCWD1084506

Courtesy of CHRYSLER

Fig 2: Coil-Ignition 5 Component Location (2.9L)

GCWD1267912

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

F342

WH/RD

1

FUSED ASD RELAY OUTPUT

2.9L

2

Z909

BK

1.5

GROUND

2.9L

3

K16

WH/DB

0.75

COIL CONTROL 5

2.9L

4

Z75

BN/DB

0.50

IONIZATION SIGNAL 5

2.9L

⁽¹⁾	Pins not listed are not used for this connector
