Sensor-Exhaust Differential Pressure (EU6) Connector End View (D3264A)

Harness-Family: Headlamp_Dash

Color: BLACK

Gender: FEMALE

Part Number: 1/11586/97

Part Description: Not Available

Connector No: D3264A

Option: EU6

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Exhaust Differential Pressure Connector End View (EU6)

Courtesy of CHRYSLER

Fig 2: Sensor-Exhaust Differential Pressure Component Location (EU6)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F860

WH/DB

0.75

EGR 5 VOLT SUPPLY

EU6

K666

WH/BK

0.75

SENSOR RETURN

EU6

K691

WH/GN

0.75

EGR COOLER TEMP SIGNAL

EU6

⁽¹⁾	Pins not listed are not used for this connector
