Post-Remote Jump-Positive C1 (2.9L) Connector End View (D7402A)

Harness-Family: Battery_Positive_29L

Color: NA

Gender: FEMALE

Part Number: KKTE16263-A

Part Description: Not Available

Connector No: D7402A

Option: 2.9L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Post-Remote Jump-Positive C1 Connector End View (2.9L)

Courtesy of CHRYSLER

Fig 2: Post-Remote Jump-Positive C1 Component Location (2.9L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
