Fuse F18 10A (Standard) Connector End View (F18)

Harness-Family: PDC_Rear

Color: NA

Gender: MALE

Part Number: Fuse-Ckt_Breaker

Part Description: Not Available

Connector No: F18

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Fuse F18 10a Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Fuse F18 10a Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

B(+)

N/A

A214

FUSED B(+)

PREMIUM

⁽¹⁾	Pins not listed are not used for this connector
