Sound Generator (2.9L) Connector End View (D2705A)

Harness-Family: Injector_LT

Color: BLACK

Gender: FEMALE

Part Number: 1/11586/97

Part Description: Not Available

Connector No: D2705A

Option: 2.9L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sound Generator Connector End View (2.9L)

GCWD1012597

Courtesy of CHRYSLER

Fig 2: Sound Generator Component Location (2.9L)

GCWD1267830

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K625

GN/WH

0.5

SOUND GENERATOR (+)

2.9L

2

Z909

NA

0.5

GROUND

2.9L

3

K626

BK/WH

0.5

SOUND GENERATOR (-)

2.9L

⁽¹⁾	Pins not listed are not used for this connector
