Speaker-Tweeter-Rear Door-Right (Premium) Connector End View (D2949A)

Harness-Family: Door_Right_Rear_Jumper

Color: BLACK

Gender: FEMALE

Part Number: 1/05989/87

Part Description: Not Available

Connector No: D2949A

Option: PREMIUM

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Speaker-Tweeter-Rear Door-Right Connector End View (PREMIUM)

Courtesy of CHRYSLER

Fig 2: Speaker-Tweeter-Rear Door-Right Component Location (PREMIUM)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X394

OG/BK

0.75

AMPLIFIED RIGHT REAR SPEAKER (-)

PREMIUM 2

X304

0.75

AMPLIFIED RIGHT REAR SPEAKER (+)

PREMIUM 2

⁽¹⁾	Pins not listed are not used for this connector
