Microphone-Shaker (Standard) Connector End View (D1552A)

Harness-Family: Headlamp_Dash

Color: BLACK

Gender: FEMALE

Part Number: 1/11586/97

Part Description: Not Available

Connector No: D1552A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Microphone-Shaker Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Microphone-Shaker Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K245

0.5

ENGINE ON SIGNAL

2.0L

Z111

0.5

GROUND

2.0L

⁽¹⁾	Pins not listed are not used for this connector
