Switch-Hood Ajar 2 (Standard) Connector End View (D2351A)

Harness-Family: Headlamp_Dash

Color: BLACK

Gender: FEMALE

Part Number: 1/12633/97

Part Description: Not Available

Connector No: D2351A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Switch-Hood Ajar 2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Switch-Hood Ajar 2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K806

WH/BK

0.75

STOP START HOOD AJAR SW SIG

2.0L EXCEPT EXPORT

Z101

BK/GN

0.5

GROUND

2.0L EXCEPT EXPORT

⁽¹⁾	Pins not listed are not used for this connector
