Switch-Seat Adjuster-Driver Lumbar (Standard) Connector End View (D2288A)

Harness-Family: Seat_Driver

Color: BLACK

Gender: FEMALE

Part Number: 15326900

Part Description: Not Available

Connector No: D2288A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Switch-Seat Adjuster-Driver Lumbar Connector End View (Standard)
GCWD1006373Courtesy of CHRYSLER
Fig 2: Switch-Seat Adjuster-Driver Lumbar Component Location (Standard)
GCWD1268150Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
A P107 RD 0.5 DRIVER SEAT LUMBAR IN DRIVER EXCEPT POWER BOLSTER
B P172 WH 0.5 LUMBAR DOWNWARD DRIV EXCEPT POWER BOLSTER
B P101 WH 0.5 DRIVER SEAT LUMBAR INFLATE UPPER DEFLATE LOWER DRIVER POWER BOLSTER
C P105 GN 0.5 DRIVER SEAT LUMBAR OUT DRIVER EXCEPT POWER BOLSTER
C P102 GN 0.5 DRIVER SEAT LUMBAR INFLATE LOWER DEFLATE UPPER DRIVER POWER BOLSTER
E P170 VT 0.5 LUMBAR UPWARD DRIV EXCEPT POWER BOLSTER
F A214 BU/RD 0.5 FUSED B(+) EXCEPT POWER BOLSTER
E P105 VT 0.5 DRIVER SEAT LUMBAR OUT DRIVER POWER BOLSTER
(1) Pins not listed are not used for this connector
